Big Cube 226
 Post Reply Post Reply
Author
Message
  Topic Search Topic Search  Topic Options Topic Options
Conley707 View Drop Down
Bronze Level
Bronze Level


Joined: 24 Jul 2022
Location: Michigan
Points: 7 		Post Options Post Options   Thanks (0) Thanks(0)   Quote Conley707 Quote  Post ReplyReply Direct Link To This Post Topic: Big Cube 226
    Posted: 24 Jul 2022 at 4:32pm
I am sure it has been talked about before. But what are some of the bigger 226 builds out there? And what is to big?
We are pondering the idea of a 485 cube.
Back to Top
Sponsored Links


Back to Top
DrAllis View Drop Down
Orange Level Access
Orange Level Access


Joined: 12 Sep 2009
Points: 20525 		Post Options Post Options   Thanks (0) Thanks(0)   Quote DrAllis Quote  Post ReplyReply Direct Link To This Post Posted: 24 Jul 2022 at 4:41pm
Let us know how that works out. I've heard of some in the 440 cube range and also heard they maybe don't last all that long. Both will require custom rods or rods much smaller in diameter on the crankshaft end. Bore max for me is 4.630" and the block eventually splits down the middle.  I've gotten by for years at 390+ cubes with a ton of compression.
Back to Top
Conley707 View Drop Down
Bronze Level
Bronze Level


Joined: 24 Jul 2022
Location: Michigan
Points: 7 		Post Options Post Options   Thanks (0) Thanks(0)   Quote Conley707 Quote  Post ReplyReply Direct Link To This Post Posted: 24 Jul 2022 at 6:18pm
One concern is can i feed that kinda cubes with a leroy head. We cant run custom intakes or heads in D3 as of right now we are going to try 4.875 by 6.5.
Back to Top
DrAllis View Drop Down
Orange Level Access
Orange Level Access


Joined: 12 Sep 2009
Points: 20525 		Post Options Post Options   Thanks (0) Thanks(0)   Quote DrAllis Quote  Post ReplyReply Direct Link To This Post Posted: 24 Jul 2022 at 6:58pm
Don't know how you'll ever get a 4.875" bore unless the LeeRoy block is better than a D-17 block.
Back to Top
Robacpuller View Drop Down
Silver Level
Silver Level
Avatar

Joined: 07 Apr 2016
Location: Wisconsin
Points: 248 		Post Options Post Options   Thanks (0) Thanks(0)   Quote Robacpuller Quote  Post ReplyReply Direct Link To This Post Posted: 24 Jul 2022 at 8:44pm
4.600 bore, 6.250 stroke.
Mine is 4.600 bore 6 inch stroke. A lot of air flow work.
Really good cam. 290 lbs of compression low 120's for power.
18.4 x 34 tires
Back to Top
d17brown View Drop Down
Orange Level
Orange Level
Avatar

Joined: 11 Sep 2009
Location: farley iowa
Points: 1689 		Post Options Post Options   Thanks (0) Thanks(0)   Quote d17brown Quote  Post ReplyReply Direct Link To This Post Posted: 07 Aug 2022 at 8:32pm
had a 429 cubed D17, not much room left. just saying
phil
Back to Top
allispuller45 View Drop Down
Bronze Level
Bronze Level
Avatar

Joined: 05 Dec 2022
Location: DeHart
Points: 2 		Post Options Post Options   Thanks (0) Thanks(0)   Quote allispuller45 Quote  Post ReplyReply Direct Link To This Post Posted: 05 Dec 2022 at 8:16pm
You cant make one that big. We have a 226 that is has been bored and stroked to 419. and it is about the max you can safely build one in my opinion.
Back to Top
cms View Drop Down
Bronze Level
Bronze Level


Joined: 29 Nov 2010
Location: collinsville il
Points: 70 		Post Options Post Options   Thanks (0) Thanks(0)   Quote cms Quote  Post ReplyReply Direct Link To This Post Posted: 07 Dec 2022 at 9:04am
450 is possible, have a 426 in shop for freshening up that can be bought.
Back to Top
Conley707 View Drop Down
Bronze Level
Bronze Level


Joined: 24 Jul 2022
Location: Michigan
Points: 7 		Post Options Post Options   Thanks (0) Thanks(0)   Quote Conley707 Quote  Post ReplyReply Direct Link To This Post Posted: 07 Dec 2022 at 10:09am
What's the info on that engine?

Back to Top
NEVER green View Drop Down
Orange Level Access
Orange Level Access


Joined: 28 Feb 2013
Location: MN.
Points: 7498 		Post Options Post Options   Thanks (0) Thanks(0)   Quote NEVER green Quote  Post ReplyReply Direct Link To This Post Posted: 07 Dec 2022 at 11:00am
If you filled the water jackets with liquid cast would that help strengthen the block??
2-8050 1-7080 6080 D-19 modelE & A 7040   R50
Back to Top
cms View Drop Down
Bronze Level
Bronze Level


Joined: 29 Nov 2010
Location: collinsville il
Points: 70 		Post Options Post Options   Thanks (0) Thanks(0)   Quote cms Quote  Post ReplyReply Direct Link To This Post Posted: 08 Dec 2022 at 8:12am
The 426 is 4.625/6.3125. the 450 was 4.75/6.25. The 426 was easier to keep running. The 426 is built inside a 201 block. Have plans on going to 6.375 on the next build and keep a nice size journal.
Back to Top
41wc View Drop Down
Bronze Level
Bronze Level


Joined: 11 Sep 2022
Location: OH
Points: 3 		Post Options Post Options   Thanks (0) Thanks(0)   Quote 41wc Quote  Post ReplyReply Direct Link To This Post Posted: 27 Dec 2022 at 7:23pm
How are you keeping the mains intact and not tearing themselves out of the 201 block? I do not mean that sarcastically, I have one I’m trying to figure that out on right now. I’m assuming billet main caps, but I’ve been warned that my 391ci is going to pull the mains out.

Edited by 41wc - 27 Dec 2022 at 7:24pm
Back to Top
