 Topic: Model B Flat Tire
Posted: 14 Oct 2024 at 9:11pm |
|
Never expected this, but my AC Model B has a flat tire. What is the process for repairing it? Do I need to remove the entire wheel? Does the rim separate from the wheel while the wheel stays in place on the tractor? Can someone steer me someplace where I can find step-by-step instructions? Instructions are not in the manuals and I never had to deal with this before now. I would prefer not to take the entire tractor to a shop and have them do the work. If possible, I would like to take the wheel or rim with tire in place and have them repair it. Thanks for your help.
|
 |
|
Sponsored Links
|
|
|
steve(ill)
Orange Level Access
Joined: 11 Sep 2009
Location: illinois
Points: 81772
|
Post Options
Thanks(0)
Quote Reply
Posted: 14 Oct 2024 at 10:12pm |
if you are talking about a Model B Farm tractor.... the front rim/ tire is held on by 5 bolts, just like an automobile. Remove the bolts and the rim / tire comes off..
If your talking about the rear tire ... the center hub stays on the tractor. The tire / rim is help on by 4 bolts, 5/8 inch diameter .... there are 4 CLAMPS that wedge the rim to the hub... Jack the tire 1 inch off the ground and remove the 4 bolts / nuts/ clamps and the rim / tire will come off..
Edited by steve(ill) - 14 Oct 2024 at 10:24pm
|
|
Like them all, but love the "B"s.
|
|
55allis
Orange Level
Joined: 30 Jun 2020
Location: Griswold Iowa
Points: 726
|
Post Options
Thanks(0)
Quote Reply
Posted: 14 Oct 2024 at 10:13pm |
|
If it’s the same as my brothers ib than it’s just 5 bolts (I think a 5/8” wrench) and the rim will be removed.
steve(ill) I think we just posted at the same time…. Ha ha
Edited by 55allis - 14 Oct 2024 at 10:15pm
|
|
1955 AC WD45 diesel with D262 repower, 1949 AC WD45
|
|
steve(ill)
Orange Level Access
Joined: 11 Sep 2009
Location: illinois
Points: 81772
|
Post Options
Thanks(0)
Quote Reply
Posted: 14 Oct 2024 at 10:19pm |
dont see a movie on the ALLIS... but this is very similar.... look at the 7:30 time mark and you will get the idea..
|
|
Like them all, but love the "B"s.
|
|
Monk
Bronze Level
Joined: 11 Nov 2012
Location: Florida
Points: 58
|
Post Options
Thanks(0)
Quote Reply
Posted: 15 Oct 2024 at 5:36am |
|
Sorry I didn't specify. It's the rear tire. Appears to be an issue with the tube or valve stem. In either case, the tire may have to come off in order to repair unless I can leave the tire on the rim; take one side off the rim in order to remove the tube and replace or repair it.
|
|
im4racin
Orange Level
Joined: 12 Jun 2017
Location: Garrison ND
Points: 954
|
Post Options
Thanks(0)
Quote Reply
Posted: 15 Oct 2024 at 6:22am |
|
It will be easier for them if it's mounted to the tractor
|
|
steve(ill)
Orange Level Access
Joined: 11 Sep 2009
Location: illinois
Points: 81772
|
Post Options
Thanks(0)
Quote Reply
Posted: 15 Oct 2024 at 9:54am |
In either case, the tire may have to come off in order to repair unless I can leave the tire on the rim; take one side off the rim in order to remove the tube and replace or repair it.
You have to break the bead on BOTH SIDES, to move the tire on the rim far enough to get the tube out... Normally you will REMOVE the tire and clean / inspect the rim , then reinstall ONE SIDE of the tire, install the new TUBE and then pop the other side of the tire over the rim.... as i said above, just take the 4 clamps off and load the tire up in the truck and take to the TIRE GUY...
|
|
Like them all, but love the "B"s.
|
|
55allis
Orange Level
Joined: 30 Jun 2020
Location: Griswold Iowa
Points: 726
|
Post Options
Thanks(0)
Quote Reply
Posted: 15 Oct 2024 at 10:30am |
|
I’ve done (and plenty more to go) dozens of rear tractor tires, and only did one on a tractor. An A-C B rear tire is small enough to handle by hand so in my case it’s easier to remove the rim and all so I can move, flip around, and break the bead.
|
|
1955 AC WD45 diesel with D262 repower, 1949 AC WD45
|
|
IBWD MIke
Orange Level
Joined: 08 Apr 2012
Location: Newton Ia.
Points: 3791
|
Post Options
Thanks(0)
Quote Reply
Posted: 16 Oct 2024 at 8:36am |
 55allis wrote:
I’ve done (and plenty more to go) dozens of rear tractor tires, and only did one on a tractor. An A-C B rear tire is small enough to handle by hand so in my case it’s easier to remove the rim and all so I can move, flip around, and break the bead. |
55, I've done them both ways and since getting the proper tools, screw-type bead breaker is the big one, much prefer to do them on the tractor. Did a pair of 16.9x38's and a pair of 20.8x38's this year, those 18x38" wheels are heavy!
|
|
