I just picked up a B112, the wiring has had a little too much tlc over the years and it's a mess. I'm wanting to change the harness...is it the same wiring as a B110? Any help would be great.
Back to Top
Sponsored Links


Back to Top
ACmowerguy View Drop Down
Orange Level
Orange Level
Avatar

Joined: 20 Apr 2010
Location: Winfield, MO
Points: 1209 		Post Options Post Options   Thanks (0) Thanks(0)   Quote ACmowerguy Quote  Post ReplyReply Direct Link To This Post Posted: 26 Aug 2016 at 9:38pm
There were two wiring systems used on a B-112 or B-110. One system has a push button start switch and no solenoid (early system). The newer ones had just a regular ignition switch and has a solenoid on the generator bracket. The systems for B-110 and B-112 are interchangeable as long as you are swapping early for early or late with late.
10 various B-series garden tractors, AC Homesteader8, 416 hydro,710 gt, 914, 916H, 917H, 920D, and many misc attachments
